12
U0TX
+3V3SB
U0RX
J3
4x1 W/HOUSING
DIP4/W/H/P2.0
1
2
3
4
3.3.B Board…….(Power Board)
3.3.1 Function Description:
Supply power for Main board, Panel.
3.3.2Connectordefinition
INPUT CONNECTOR (CN6)
3.4. LCD PANNEL.
CN6 Signal name
1 N
2 GND
3 GND
4 DIM
5 EN
6 +12V
7 +12V
