8. DISASSEMBLY INSTRUCTIONS
8.1.whole machine
The whole machine includes Packaging subassembly、Front-frame subassembly、Back-cover
subassembly、Base subassembly、MAINBOARD SUBASSEMBLY、Remote Control Board
Subassembly、Control Board Subassembly、Assembly Material Subassembly、Romoter Contral
Per-setting Subassembly.
3.2 3.3 3.5
3.6 3.7 3.8
Components List
NO Name Description Parts number
1 HLC19R whole machine
2 Packaging
/
3 TV Set
/
3.1 Base subassembly
3.2 Back cover subassembly
3.3 Front Frame Subassembly
3.4 Assembly Material Subassembly
3.5 Control Board Subassembly
3.6 Remote Control Board
Subassembly
3.7
Mainboard Subassembly
3.8
DVD
