6. DISASSEMBLY INSTRUCTIONS
6.1.Whole machine
The whole machine includes Packaging Assembly、Front Cabinet Assembly、Back Cabinet Assembly、
Base Assembly、Main board Assembly、Remote Control Board Assembly、Control Board Assembly、
Assembly Material Subassembly、Romote Contral Per-setting Assembly.
1 2
3.2 3.3 3.4
3.5 3.6 3.7
Components List
NO Name Description Parts number
1 HLC22R whole machine
2 Packaging
/
3 TV Set
/
3.1 Support Stand Assembly
3.2 Back Cabinet Assembly
3.3
Keypad Assembly
3.4 Front Cabinet Assembly
3.5 Remote Control Board Assembly
3.6
Main board Assembly
3.7 DVD
