23
Assembly
Spare parts
number
Location
No.
Spare Parts Name in English Specification Qty
Front Cabinet Assembly 1
Front Cabinet Subassembly 1
Plastic Front Cabinet 1
Transparent Window
silk-screen：DYNEX
1
Plastic board 1
Bolt
SJ2824-87
ST3X10F
2
Front Cabinet
Assembly
Bolt SJ2824-87 ST3*10F 2
6.5. Miscellaneous Material Assembly
6.5.1. Location Photo
6.5.2 Components List
Assembly
Spare parts
number
Location
No.
Spare Parts
Name in
English
Specification Qty
Miscellaneous
Material Assembly
1
