21
6.2. Support Stand Assembly
Assembly
Spare parts
number
Location
No.
Spare Parts Name in
English
Specification Qty
0090714705
Support Stand Assembly
1
0090202154 Base Subassembly 1
0090202154.1 Base Board(Black) 1
0090202154.2 Rotational Axis 1
0090202154.3 Rubber 5
0090202154.4 Bolt
Support Stand
Assembly
4
Support Stand
Assembly
0090600198 Bolt
GB818-85
M4X16
4
6.3. Back Cabinet Assembly
Components List
Assembly
Spare parts
number
Location
No.
Spare Parts Name
in English
Specification Qty
