HSU-09(12)HA/HVA/RHA103/R2(DB) Capacity
42
Domestic air conditioner
outdoor temp.
(humidity 46%)
DB/WB 16℃
19
℃
22℃
15
℃
2053 2255 2336
25
℃
2078 2210 2321
30
℃
2451 2623 2694
35
℃
2764 2890 2971
40
℃
3075 3156 3247
45
℃
3429 3600 3641
HSU-09HA103/R2(DB)
performance curves
COOLING DISCHARGE PRESSURE
.talbe
in
door temp.
COOLING DISCHARGE PRESSURE
1500
2000
2500
3000
3500
4000
15℃ 25℃ 30℃ 35℃ 40℃ 45℃
Outdoor Temp
D
I
SC
H
ARGE PR ESSURE
16℃
19℃
22℃
9.5 Cooling Discharge Pressure Curves
