Haier HSU-09/12HA103/R2(DB) User Manual

HSU-09(12)HA/HVA/RHA103/R2(DB) Capacity
60
Domestic air conditioner
outdoor temp.
(humidity 46%)
DB/WB 15℃
20
℃
25℃
－
15
℃
260 259 262
－
10
℃
325 330 340
－
5
℃
394 415 420
0℃ 430 470 478
5
℃
470 540 545
10℃ 600 648 682
15
℃
757 757 818
20
℃
719 749 762
HSU-09HA103/R2(DB) performance curves
HEATING SUCTION PRESSURE.talbe
in
door temp.
HEATING SUCTION PRESSURE
0
100
200
300
400
500
600
700
800
900
1000
－15℃ －10℃ －5℃ 0℃ 5℃ 10℃ 15℃ 20℃
Outdoor Temp
DI
S
CH
A
RG
E
PR
ESS
U
R
E
15℃
20℃
25℃
9.8 Heating Suction Pressure Curves
