SERVICE MANUAL
Front Load Washing Machine
HW50-1002W
Important: The height of the top of
the curve in the drain hose MUST
be between 80 - 100cm from the
floor (9).
Fit the drain hose into
the hose clip (10 ) and
attach to the wall etc.
at the correct height.
Max.
100cm
Min.
80cm
Drain hose connection
9
10
HW50-1010W
C
。
90
C
。
60
C
。
40
C
。
40
C
。
30
8- 4. Drainage Hose
