SERVICE
MANAUL
HW50-1002W
Front Load Washing Machine
22
light of synthetic 0 ℃ on
1050/1060
light of synthetic 30 ℃ on
950/960
light of quick wash on 850/860
light of cotton pre-wash on 750/760
light of cotton & flax 90 on 650/660
washing program indication
light
Corresponding spin
speed
X.3 The model can only be selected from high spin speed to lower spin speed, once
saved, it can’t reverse adjust, however, when the Temperature sensor is off, it can.
Chapter 10 Error Display and troubleshooting
10-1. The start indicator lighted on 0.2s and off 0.2s for twice, repeat 4s
later
Error 1
The start indicator wasn't lighted,and thebuzzer sound abnormally.
Error message:Door is not properly shut 20s after program is started.
Troubleshooting:
Error 2
The start indicator lighted on 0.2s andoff 0.2s for twice,repeat 4s later .
Error message: Drainage error, water not emptied wit
hin 4 min.
Pushing the door to Check Whether
Door is properly shut or not
Shut the door properly
Door lock is broken and need replacing,
then make sure wire is connected
properly.
Check the voltage between 12-3 and
12-12 of PCB, is it between AC
220-240V?
Cut off the power and then turn on again.
Check the voltage between brown wire
and blue wire of door lock, is it between
AC 220-240V?
N
Replace
PCB
N
Connect the wire properly
Check if the wire connecting door lock
and PCB is loose
N
Y
Y
To Next Page
