NOTE
WAIT FOR FAN TO STOP BEFORE CHANGING
THE SETTING OF THE SLIDE SWITCH.
Figure 21
Figure 22
Cool weather - (Clockwise direction) An
upward airflow moves warm air off the
ceiling area. (Fig. 22) This allows you to set
your heating unit on a lower setting without
affecting your comfort.
9
Figure 19
Figure 20
Switch housing
Glass shade
Finial
Metal Cap
Metal Nut
Rubber Washer
Metal Washer
Operating your fan
Turn on the power and check the operation of
your fan. There are three pull chains
available in your fan:
1. 3-speed Pull chain-it controls the fan
spe e d as follows: 1 pull- High, 2 pulls-
Medium, 3 pulls- Low, and
4 pulls-
Off.
Speed settings for warm or cool weather
depend on factors such as the room size,
ceiling height, number of fans, and so on.
2. Light kit pull chain-it controls the light kit
in “ON” or “OFF”.
The slide switch controls directions: forward
(switch left ) or reverse (switch right ).
Wa r m w e a t h e r - ( C o u n t e r - C l o c k w i s e
direction) A downward air flow creates a
cooling effect.(Fig. 21) This allows you to
set your air conditioner on a higher setting
without affecting your comfort.
