3
1
2
6
4
7
9
13
B
A
5
10
8
11
12
9. Flywheel (1)
10. Light kit (1)
11. 40 Watt E12 bulb (3)
12. Glass shade (1)
1.
2. Hanger bracket (1)
3. Canopy (1)
4. Canopy cover (1)
5. Ball/downrod assembly (1)
6. Coupling cover (1)
7. Fan motor assembly ( 1 )
8. Set of blades brackets (5)
Set of blades (5)
WARNING
DO NOT INSTALL OR USE FAN
IF ANY PART IS DAMAGED OR MISSING.
CALL TOLL FREE 1-800-527-0998
Unpack your fan and check the contents. You should have the following items:
2
D
E
F
Loose parts bag containing:
A. Mounting hardware
Plastic wire connectors (3pcs)
B . Blade attachment hardware
3/16″ 6mm
Screw(16pcs)
×
Fiber washer (16pcs)
C. Blade bracket hardware
1/4*9.5mm screws (10pcs)
Flywheel hardware
1/4*9.5mm screws (6pcs)
D. Extra plug with nut (1)
E.
F.
Pull chain fob (2pcs)
Balancing kit (1)
(2pcs)
Unpacking Your Fan
Unpack your fan and check the contents. You should have the following items:
C
