SCPI Programming Reference
HDG2000 Series Arbitrary Waveform Generator 73
Parameter
Typical Return
AUTO AUTO
USER1 1 ms
USER2 10 ms
USER3 100 ms
USER4 1 s
USER5 10 s
USER6 >10 s
AUTO, USER1, USER2, USER3, USER4, USER5,
or USER6
COUNter:TYPE LFCOUNTER|LFFREQ|HFCOUNTER|HFFREQ
Set counter type.
Parameter
Typical Return
LF_COUNTER|LF_FREQ|HF_COUNTER
|HF_FREQ, default LF_COUNTER
LF_COUNTER, LF_FREQ|HF_COUNTER, or
HF_FREQ
5.2.7 DATA Subsystem
The DATA subsystem manages user-defined arbitrary waveforms.
SOURce<n>:DATA:DAC16 <addr>,<dots_num>,<binary_block>| <value>,<value>, . . .
Download data (.dac format) to ddr2
SOURce<n>:DATA: <addr>,<dots_num>,<binary_block>| <value>,<value>, . . .
Download data (float format) to ddr2
SOURce<n>:DATA:OUTPut <start_addr>,<end_addr>
Output data in specified address.
SOURce<n>:DATA:DAC16 <addr>,<dots_num>,<binary_block>| <value>,<value>, . . .
Parameter
Typical Return
<addr> Hexadecimal number, from 0x00to 64M, 4Byte
none
<dots_num> Decimal number
<binary_block> Binary number, dots_num*2 byte, starting as “#”
<value> Integer, from -32767 to +32767
SOURce<n>:DATA: <addr>,<dots_num>,<binary_block>| <value>,<value>, . . .
Parameter
Typical Return
<addr> Hexadecimal number, from 0x00to 64M, 4Byte
无
<dots_num> Decimal number
<binary_block> Binary number, dots_num*4 byte, starting as “#”
<value> Integer, from -1 to +1
