Hantek HDG2022B User Manual

SCPI Programming Reference
HDG2000 Series Arbitrary Waveform Generator 89
SYSTem:ROSCillator:SOURce INTernal|EXTernal
SYSTem:ROSCillator:SOURce?
Parameter
Typical Return
INTernal|EXTernal, default INTernal
INTernal, or EXTernal
Use the external reference oscillator source: SYSTem:ROSCillator:SOURce EXTernal
 EXTernal:instrument uses signal on the rear-panel 10 MHz In connector as reference, and
generates an error if this signal is absent or the instrument cannot lock to it. In such error cases,
instrument output continues, but the frequency will be unstable.
 INTernal: instrument uses the internal reference oscillator and ignores the signal at the 10
MHz In connector.
5.2.24 SOURce Subsystem
Subsystems Using the Optional SOURce Keyword
Because SOURce subsystem commands are often used without the SOURce keyword, these
commands are listed by their individual subsystems, below:
AM
ASK
BPSK
BURSt
DATA
FM
FREQuency
FSKey
FUNCtion
MARKer
PHASe
PM
ROSCillator
SWEep
VOLTage
5.2.25 SWEepSubsystem
SOURce<n>:SWEep:HTIMe <seconds>|MINimum|MAXimum
SOURce<n>:SWEep:HTIMe? [MINimum|MAXimum]
Sets number of seconds the sweep holds (pauses) at the stop frequency before returning to the

Hantek HDG2022B Specifications

General

Category	Function/Arbitrary Waveform Generator
Model	HDG2022B
Brand	Hantek
Channels	2
Sample Rate	100 MSa/s
Interface	USB Device, USB Host
Vertical Resolution	14 bits
Waveforms	Sine, Square, Pulse
Arbitrary Waveform Length	8kpts
Modulation Types	AM, FM, PM
Power Supply	100-240V AC
