Hantek HDG2032B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
103
Appendix B
Model
HDG
2102B
HDG
2082B
HDG
2062B
HDG
2032B
HDG
2022B
HDG
2012B
HDG
2002B
Main Features
Channel
2
Memory Depth
64M
Frenquency
100MHz
80MHz
60MHz
30MHz
20MHz
10MHz
5MHz
Sample Rate
250MSa/s
Voltage Resolution
16Bit
Digital Output
16 Channels output
Frenquency Characteristic
Standard Waveforms
Sine, Square, Ramp, Pulse, Noise, Sinc, Exponential Rise, Exponential Fall, ECG,
Gauss, Haver Sine, Lorentz, Dual-Tone, DC
Sine
1uHz~Max.
Square
1uHz~30MHz
1uHz~Max.
Pluse
1uHz~15MHz
1uHz~Max.
Ramp/Triangle
1uHz~4MHz
1uHz~3MHz
White Noise
100MHz
80MHz
60MHz
30MHz
20MHz
10MHz
5MHz
Arb.
1uHz~
20MHz
1uHz~
20MHz
1uHz~
20MHz
1uHz~
20MHz
1uHz~
15MHz
1uHz~
10MHz
1uHz~
5MHz
Resolution
1uHz
Accuracy
±50ppm, 18~28℃
Sine Wave Spectrum Purity
Harmonic Distortion
Typical(0dBm) DC-1MHz: <-60dBc; 1MHz-10MHz: <-55dBc; 10MHz-100MHz:
<-50dBc
Total Harmonic
Distortion
<0.1% (10Hz-20kHz, 0dBm)
Spurious signal
(non-hormonic)
Typical(0dBm): ≤10MHz: <-65dBc;
>10MHz <-65dBc+6dB/spectrum phase
Phase Noise
Typical(0dBm,10kHz offset,) 10MHz: ≤-115dBc/Hz
Square
Rise/Down time
<10ns
<11ns
<12ns
<14ns
<16ns
<18ns
<18ns
Overshoot
<3%(100KHz, 1Vpp)
Duty Cycle
≤10MHz: 20.0%~80.0%;
10MHz~40MHz: 40.0%~60.0%;
>40MHz: 50.0%
8.0%~92.0%
Non-symmetry
1% of period+5ns
