Hantek HDG2102B User Manual

SCPI Programming Reference
HDG2000 Series Arbitrary Waveform Generator 67
SOURce<n>:MOD:FM:SOURce INTernal|EXTernal
SOURce<n>:MOD:FM:SOURce?
SOURce<n>:MOD:PM:SOURce INTernal|EXTernal
SOURce<n>:MOD:PM:SOURce?
SOURce<n>:MOD:ASKey:SOURce INTernal|EXTernal
SOURce<n>:MOD:ASKey:SOURce?
SOURce<n>:MOD:FSKey:SOURce INTernal|EXTernal
SOURce<n>:MOD:FSKey:SOURce?
SOURce<n>:MOD:PSKey:SOURce INTernal|EXTernal
SOURce<n>:MOD:PSKey:SOURce?
SOURce<n>:MOD:BPSKey:INTernal:RATE <frequency>|MINimum|MAXimum
SOURce<n>:MOD:PWM:SOURce INTernal|EXTernal
SOURce<n>:MOD:PWM:SOURce?
Select the source of the modulating signal.
Parameter
Typical Return
INTernal|EXTernal, default INTernal
INTernal, or EXTernal
Select external modulation source of CH1: SOURce1:MOD:AM:SOURce EXTernal (could also
substituteASK, FM, BPSK, FSK, PM, PSAK or PWM for AM)
SOURce<n>:MOD ON|OFF
SOURce<n>:MOD?
Enables or disables modulation.
Parameter
Typical Return
ON|OFF, default OFF
ON, or OFF
Enable modulation: SOURce1:MOD ON
SOURce<n>:MOD:TYPe AM|FM|PM|ASK|FSK|PSK|PWM|BPSK
SOURce<n>:MOD:TYPe?
Select modulation type
Parameter
Typical Return
TYPe AM|FM|PM|ASK|FSK|PSK|PWM|BPSK,
default AM
AM, FM, PM, ASK, FSK, PSK, PWM or BPSK
Set FM modulation: SOURce<n>:MOD:TYPe FM
