harman/kardon AVR132/230
DIGITAL IN/OUT PCB (CUP11916-1)
Ref# Component Description Description 2 Qty
CUP11916-1 PCB , DIGITAL IN/OUT PCB 1
BN17 KJP12GB143ZP DIP SOCKET SOCKET 1
C750 CCEA1CH101T CAP , ELECT 100UF 16V 1
C751 CCEA1CH101T CAP , ELECT 100UF 16V 1
C754 HCBS1H181KBT CAP , CERAMIC 180PF 50V 1
C757 CCFT1H104ZF
CAP ,
SEMICONDUCTOR
0.1UF 50V ZF 1
C760 CCFT1H473ZF CAP, CERAMIC 0.047UF 50V ZF 1
C761 CCEA1CH101T CAP , ELECT 100UF 16V 1
IC72 HVI74HCU04AFNG I.C , INVERTER TOSHIBA 1
JK75 HJSTORX177L
MODULE ,
OPTICAL(RX)
OPTICAL JACK 1
JK76 HJSTORX177L
MODULE ,
OPTICAL(RX)
OPTICAL JACK 1
JK78 CJJ4S022Z JACK , BOARD JACK 1
JK79 CJJ4N068Z JACK , BOARD JACK 1
R750 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R751 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R757 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R765 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R766 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
R767 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
R768 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
R770 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R771 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R776 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
BIAS TR PCB (CUP11916-2)
Ref# Component Description Description 2 Qty
CUP11916-2 PCB , BIAS TR PCB 1
C851 CCEA1HH100T CAP , ELECT 10UF 50V 1
C852 CCEA1HH100T CAP , ELECT 10UF 50V 1
C853 CCEA1HH100T CAP , ELECT 10UF 50V 1
C854 CCEA1HH100T CAP , ELECT 10UF 50V 1
C855 CCEA1HH100T CAP , ELECT 10UF 50V 1
CN31 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN32 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN33 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN34 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN35 CJP02GA19ZY WAFER, 2PIN WAFER 1
Q851 HVTKTD600KGR T.R , BIAS KTD600KGR 1
Q852 HVTKTD600KGR T.R , BIAS KTD600KGR 1
