Harman Kardon AVR 132 Service Manual

harman/kardon AVR132/230
RDS PCB (CUP11931-2)
Ref# Component Description Description 2 Qty
C755 CCUS1H561JA CAP , CHIP 560PF 1
C767 HCEC1CRV2100T CAP , ELEC (SMD) 10UF / 16V 1
C774 HCEC1CRV2101T CAP , ELEC (SMD) 100UF / 16V 1
R703 CRJ10DJ103T RES , CHIP 10K OHM 1
R706 CRJ10DJ222T RES , CHIP 2.2K OHM 1
R707 CRJ10DJ222T RES , CHIP 2.2K OHM 1
R708 CRJ10DJ101T RES , CHIP 100 OHM 1
BN49 CWB2B905080EN WIRE ASS'Y WIRE 1
CN49 CJP05GA19ZY
WAFER, STRAIGHT,
5PIN
WAFER 1
X703 HOX04332E200C CRYSTAL 4.3321MHz 1
IC74 HVILC72723M IC , PLL (RDS) 1
VIDEO PCB (CUP11930)
Ref# Component Description Description 2 Qty
CUP11930Z PCB , VIDEO PCB 1
C401 HCBS1H101KBT CAP , CERAMIC 100PF 1
C402 HCBS1H101KBT CAP , CERAMIC 100PF 1
C403 HCBS1H101KBT CAP , CERAMIC 100PF 1
C411 CCEA1HH100T CAP , ELECT 10UF 50V 1
C412 CCEA1HH100T CAP , ELECT 10UF 50V 1
C413 CCEA1HH100T CAP , ELECT 10UF 50V 1
C421 CCEA1HH100T CAP , ELECT 10UF 50V 1
C422 CCEA1HH100T CAP , ELECT 10UF 50V 1
C423 CCEA1HH100T CAP , ELECT 10UF 50V 1
C451 CCEA1HH100T CAP , ELECT 10UF 50V 1
C452 CCEA1HH100T CAP , ELECT 10UF 50V 1
C453 CCEA1HH100T CAP , ELECT 10UF 50V 1
C461 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C462 CCEA1CH101T CAP , ELECT 100UF 16V 1
C463 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C464 CCEA1CH101T CAP , ELECT 100UF 16V 1
C466 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C467 CCEA1CH101T CAP , ELECT 100UF 16V 1
C468 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C469 CCEA1CH101T CAP , ELECT 100UF 16V 1
C471 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C472 CCEA1CH101T CAP , ELECT 100UF 16V 1
C473 HCBS1H223ZFT CAP , CERAMIC 0.022UF 1
C474 CCEA1CH101T CAP , ELECT 100UF 16V 1
C491 HCBS1H101KBT CAP , CERAMIC 100PF 1
C492 HCBS1H101KBT CAP , CERAMIC 100PF 1
C493 HCBS1H101KBT CAP , CERAMIC 100PF 1
Harman Consumer Group International
