harman/kardon AVR132/230
REGULATOR PCB (CUP11916-5,6)
Ref# Component Description Description 2 Qty
CN96 CJP09GA01ZY
CON WAFER YMW025-
09R
WAFER 1
CN98 HJP08GB131ZK WAFER WAFER 1
CN99 CJP08GA19ZY
WAFER, STRAIGHT,
8PIN
WAFER 1
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R913 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
BN20 CWB1C905200BM WIRE ASS'Y WIRE 1
BN43 CWB1C904200BM WIRE ASS'Y WIRE 1
BN95 CWB1C903080EN WIRE ASS'Y WIRE 1
C912 CCEA0JKR3222E CAP , ELECT 2200UF 6.3V 1
C929 CCEA1VH102E CAP , ELECT 1000UF 35V 1
C930 CCEA1VH102E CAP , ELECT 1000UF 35V 1
C941 CCEA1CH682E CAP , ELECT 6800UF 16V 1
IC89 HVIL7805CP I.C, REGULATOR ST 1
IC90 HVIL7815CP I.C, REGULATOR ST 1
IC91 HVIL7915CP I.C, REGULATOR ST 1
IC93 HVIL7905CP I.C, REGULATOR ST 1
IC94 HVIL7805CP I.C, REGULATOR ST 1
IC95 HVINJM7809FA IC , REGULATOR JRC 1
INPUT PCB (CUP11931-1)
Ref# Component Description Description 2 Qty
CUP11931-1 PCB , INPUT PCB 1
C201 CCUS1H221JA CAP , CHIP 220PF 1
C202 CCUS1H221JA CAP , CHIP 220PF 1
C203 CCUS1H221JA CAP , CHIP 220PF 1
C204 CCUS1H221JA CAP , CHIP 220PF 1
C205 CCUS1H221JA CAP , CHIP 220PF 1
C206 CCUS1H221JA CAP , CHIP 220PF 1
C209 CCUS1H221JA CAP , CHIP 220PF 1
C210 CCUS1H221JA CAP , CHIP 220PF 1
C211 CCUS1H221JA CAP , CHIP 220PF 1
C212 CCUS1H221JA CAP , CHIP 220PF 1
C213 CCUS1H221JA CAP , CHIP 220PF 1
C214 CCUS1H221JA CAP , CHIP 220PF 1
C215 CCUS1H221JA CAP , CHIP 220PF 1
C216 CCUS1H221JA CAP , CHIP 220PF 1
C219 CCUS1H221JA CAP , CHIP 220PF 1
C220 CCUS1H221JA CAP , CHIP 220PF 1
C221 CCUS1H221JA CAP , CHIP 220PF 1
C222 CCUS1H221JA CAP , CHIP 220PF 1
C223 CCUS1H221JA CAP , CHIP 220PF 1
Harman Consumer Group International
