Harman Kardon AVR 132 Service Manual

harman/kardon AVR132/230
BIAS TR PCB (CUP11916-2)
Ref# Component Description Description 2 Qty
Q853 HVTKTD600KGR T.R , BIAS KTD600KGR 1
Q854 HVTKTD600KGR T.R , BIAS KTD600KGR 1
Q855 HVTKTD600KGR T.R , BIAS KTD600KGR 1
R874 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R875 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R876 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R877 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R878 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R882 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R883 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R884 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R885 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R886 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
VR81 HVN1RA221B01T
RES , SEMI FIXED(220
OHM)
RH0615C100221 1
VR82 HVN1RA221B01T
RES , SEMI FIXED(220
OHM)
RH0615C100221 1
VR83 HVN1RA221B01T
RES , SEMI FIXED(220
OHM)
RH0615C100221 1
VR84 HVN1RA221B01T
RES , SEMI FIXED(220
OHM)
RH0615C100221 1
VR85 HVN1RA221B01T
RES , SEMI FIXED(220
OHM)
RH0615C100221 1
REGULATOR PCB (CUP11916-5,6)
Ref# Component Description Description 2 Qty
CUP11916-5,6 PCB , REGULATOR PCB 1
C902 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C903 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C906 CCEA1CH101T CAP , ELECT 100UF 16V 1
C907 CCEA1CH101T CAP , ELECT 100UF 16V 1
C908 CCEA1CH101T CAP , ELECT 100UF 16V 1
C935 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C936 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C937 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C938 CCEA1CH101T CAP , ELECT 100UF 16V 1
C939 CCEA1EH101T CAP , ELECT 100UF 25V 1
C940 CCEA1EH101T CAP , ELECT 100UF 25V 1
CN89 CJP02GA01ZY
WAFER, STRAIGHT,
2PIN
WAFER 1
CN95 CJP03GA19ZY
WAFER, STRAIGHT,
3PIN
WAFER 1
Harman Consumer Group International
