Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/1513 3-90-08326c
TheAccentraPelletStoveismorethanjustautomaticignition,
it is also automatic temperature control. The automatic
systemwillallowtheresizetobeadjustedtomatchthe
heatingneedsandevenputthereoutifnecessary.Ifheat
isneededafterthereisout,theAccentraPelletStovewill
automaticallyre-igniteandadjusttheresizetomatchthe
heating need.The totally automatic room sensormode is
recommended because of its efciency.The unit can be
switched between "AUTO" and "DISABLED" at any time
duringoperation.
Igniter switch to “AUTO”
Room Temperature Mode
In“RoomTempMode”heatoutputiscontrolledautomatically
bytheRoomSensingProbe.WhentheRoomSensingProbe
callsforheat,thestovewillincreaseoutput.WhentheRoom
SensingProbeisgettingclosetothesettemperature,the
stovewillbegintoleveloffoutputandkeepthereburning
atjusttherighttemperaturetomaintainthatsetting.
High output is determined by the feed rate setting. This
setting,generallyon#4,canbeincreasedifhigherburnrates
arenecessary(Figure4.6).Theunit’smaximumburnrate
shouldnotcreatelessthan1”ofashontheburnpotfront
edge(Figure4.7).Overfeedingisnotasafetyconcern,but
fuelmaybewastedifunburnedpelletsfallintotheashpan.
In“RoomTempMode”aconstantfuelconsumptionrateis
sacricedforexactroomtemperature.Therefore,asitgets
coldermorepelletswillbeburnedautomatically.
The distribution blower speed will vary according to the
positionofthemodeselectorpointer,andresize.
Igniter switch to “AUTO”
Constant Burn Mode
Thisallowsforautomaticignitionuponstart-uponly.Theunit
canthenbesetatanydesiredsetting.Theheatoutputand
fuel consumption will remain constant regardless of room
temperature.Theunit’smaximumfeedrateshouldnotcreate
lessthan1”ofashontheburnpotfrontedge.Figure4.7.
Theunit’slowburnormaintenancesettingisaslowasitwill
go.Itwillnotgooutunlessitrunsoutoffueloristurnedoff.
Shut-Down Procedure
To kill the re or stop burning the stove, turn the Mode
Selectorto“OFF”.This will cause the re to diminish and
burnout.Whenthereburnsoutandthestovecoolsdown
everythingwillstop.
Ifyoupulltheplugtoshutdownthestove,allmotorswillstop.
Thismaycauseincompletecombustionandsmokeinthe
rebox.Iftheloaddoorisopened,thesmokemayescape.
Thebestwaytoshutdownthestoveissimplyletitrunout
ofpellets,thenthestovewillshutdownautomatically.
Room Temperature Mode: This setting will produce a room temperature
of 70 degrees with the distribution blower at medium speed.
This setting will produce medium heat with the distribution
blower on "low".
This setting will produce continuous maximum heat output
with the distribution blower at full speed.
Constant Burn Mode
E. Automatic Ignition (Continued)
