Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/1518 3-90-08326c
Feeder Chamber
This chamber may get a buildup of nes from the feeder
mechanismmovement.Thisarea should bechecked and
cleanedatleastonce a year.
To remove the feeder cover:
• Removethe(2)5/16”wingnuts.
• Slidethecoveroffofthethreadedstuds.
• Inspectandcleantheinnerchamberifnecessary.See
abovepicture.
• Reinstallthecovermakingcertainitiscenteredonthe
feederbodyandtightenthewingnutsastightlyasyou
canbyhand.
NOTE: Views are shown with the rear motor covers
removed.
Figure 5.8
G. Pellet Feeder Chamber
Figure 5.7
• Withtheblowerhousingopen,thereiseasyaccesstothe
uepipeexitingtherearoftheunit.Figure5.7.Vacuum
theuepipeasfarintothepipeaspossible.NOTE:Be
carefulwhilecleaningtheuepipenottobendtheexhaust
probe.TheESPisapproximately8"intothetubeandis
visiblewhenlookingintotheexhaust.
ESP
Becarefulnottodamageprobewhencleaningwithbrush.
Possiblepelletnesbuilduparea.
