EON712 SPECIFICATIONS
TECHNICAL SPECIFICATIONS
System Type 12IN Powered Loudspeaker
Woofer Model 712G
Woofer Size 12"
Woofer Magnet Ferrite
Woofer Voice Coil 2"
Tweeter Model 2414H Compression Driver
Tweeter Size 1''
Tweeter Magnet Neodymium
Transducer Impedence LF 4ohm rated, HF 8ohm rated
Max SPL 127dB @1m/4Pi
Freq Range -10 50Hz - 20kHz
Freq Range -3 60Hz - 20kHz
Hor Dispersion 100°
Vert Dispersion 60°
Power Rating 1300W peak / 650 RMS
AC Power Input 100V-120V or 220V-240V
Cooling Passive
LED Indicators 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs
Input Impedence 50k/100k un-balanced/balanced
Input Gain -∞ to +36db
Crossover Freq 2 kHz
I/O 2 XLR Combo Jacks / BT
1 XLR M Thru
Cabinet PP+10% Talc
Grille 16GA perforated steel with acoustically transparent black cloth backing
Suspension/Mount 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes
Handles 2, cable channel on bottom
Net Weight 14.6kg
Gross Weight 18.4kg
Product Dims 670x381x328mm 26.4x15x12.9in (HxWxL)
Shipping Dims 684x490x430mm 26.92x19.29x16.92in (HxWxL)
