24
EON718S SPECIFICATIONS
TECHNICAL SPECIFICATIONS
System Type 18IN Powered Subwoofer
Woofer Model 718G
Woofer Size 18"
Woofer Magnet Ferrite
Woofer Voice Coil 3"
Transducer Impedence 4 ohm rated
Max SPL 131dB @1m/2Pi
Freq Range -10 31Hz - 150Hz
Freq Range -3 40Hz -120Hz
Hor Dispersion Omni
Vert Dispersion Omni
Crossover Frequency 80, 100, 120hZ selectable
Power Rating 1500W / 750W RMS
AC Power Input 100V-120V or 220V-240V
Cooling Passive
LED Indicators 1 Power LED, 1 System Limit, 1 Front LED
Input Impedence 50k/100k un-balanced/balanced
Input Gain -∞ to +36db
I/O 2 XLR Combo
2 XLR M Thru
Cabinet 18mm Duraex-coated Birch Plywood
Grille 16GA perforated steel with acoustically transparent black cloth backing
Suspension/Mount 1 M20 Threaded Polecup
Handles 2
Net Weight 35.5kg
Gross Weight 42.5kg
Product Dims 674x609x637mm 26.53x24x25.1in(HxWxD)
Shipping Dims 722x743x713mm 28.4x29.3x28.1in (HxWxL)
