Igniter Switch to “MANUAL” (down position) ake
sure the unit is plugged into a 120 AC, 0 H electrical
source. The power light should be the only light lit.
NOTE: Be sure there is no fuel or other combustibles in
the ash pan prior to lighting.
1. Turn EE AUSTER to desired feed rate. No.  is good
for most pellets.
2. Turn the OE SELECTOR to O and then to the
desired mode. This will reset control and start the
combustion motor.
. Turn the TEPERATURE IAL to the desired setting.
. Clean burn pot with scraper if necessary.
5. ill burn pot with pellets, only level with front edge. (o
Not Over ill).
. Add starting gel on top of the pellets. Stir gel into pellets
for fast lighting.
7. Light starting gel with a match, and close the door.
Operation will begin when the re reaches the proper
temperature.
8. ill hopper with pellets and remove ashes as required.
Store fuel in a dry area, away from all ignition sources and
outside all limits of the stoves clearance requirements to
combustibles. o not store the fuel were it interferes with
the refueling of the stove or emptying of ashes. o not store
any ashes removed from the stove near the fuel or other
combustible materials.
W AR NING
NEV ER USE G ASOLINE, G ASOLINE-TY PE LANTER N
F UEL, K ER OSENE, CHAR COAL LIG HTER F LUID, OR
SIMILAR LIQ UIDS TO STAR T OR ' F R ESHEN UP' A F IR E
IN THIS HEATER . K EEP ALL SUCH LIQ UIDS W ELL
AW AY F R OM THE HEATER W HILE IN USE.
W AR NING
BUR NING G AR BAG E, USE OF IMPR OPER F UELS,
F IR E STAR TER S OR ALTER ING THE STOV E F OR
HIG HER HEAT OUTPUT MAY CAUSE DAMAG E TO THE
STOV E AND COULD R ESULT IN A HOUSE F IR E. USE
ONLY APPR OV ED F UELS AND F OLLOW ONLY THESE
OPER ATION G UIDELINES.
STAR TER
G EL
1. Finesaresmallpieces of broken pellets (sawdust).Finesdo
notoweasilyandoftenbuilduponthehopperfunnelbottom
angles.Thesenescanbepushedintothefeederopeningand
thenllthehopperwithpellets.Asthesystemworks,theywill
be burned.
2. The "TEST" cycle will operate the feeder motor for exactly one
minute.Turningto"TEST"againandagainmayloadtoomuch
fuelintotheburnpotcausingexcessivesmokeonstart-up.
3. The low pressure switch will not allow th feed motor to operate
iftheviewingdoorisopen.
4. Adjust Feed Rate. If this is your rst re or you are trying
differentpellets,setthefeedadjusterto#4,Figure4.8.Thisis
aconservativenumberandwillprobablyneedtobeincreased.
After you know a feed rate setting that works well, use that
setting.Remember,ifyourfeedrateistoohighyoumaywaste
fuel.
5. Setting the feed adjuster # for maximum burn: With the unit
burningin"AUTO",turnto"StoveMode"andputthefanon"H".
SettheTemperatureDialto#7.Allowtheunittoburnforabout
30minutesandcheckashonfrontofburnpot.Figure4.9.If
theashlineislargerthan1",turnthefeedadjusterfrom#4to
#5.Allowanother30minutesofburntimeandcheckagain.If
,
at#6setting,a1"orlessashbedisnotobtainable,itisnot
aproblem.The1"ashbedisonlyatmaximumburnrateand
duringnormaloperation,theashbedwillbelarger.
F . Manual Ignition
F igure 4 .8
F igure 4 .9
