Hayward Navigator Pro Troubleshoot Manual

Page 9
Figure 7
Figure 8
6. Remove the flow gauge and store for future use.
7. Check the rear flap adjuster at the left rear of the cleaner. It should be set
to Position II (fig 7)
8. Check to make sure all returns are pointed down. Returns pointed up can
interfere with the hose. Some pools may need directional eyeballs added.
9. Submerge the cleaner head and rotate to remove all air.
10. Remove the red label and connect the leader hose (fig 8)
Installation

Hayward Navigator Pro Specifications

General

Pool Type	In-ground
Warranty	2 years
Hose Diameter	1.5 inches
Pool Surface Compatibility	Concrete, Vinyl, Fiberglass
Hose Length	40 feet
Power Source	Pool's filtration system
Type	Suction-side pool cleaner
