Hayward Navigator Pro Troubleshoot Manual

Wing Removal & Replacement
Page 16
Figure 13
Figure 14
1. Using a screwdriver, remove the plugs from the pods on both
sides (fig 13).
2. Remove the wings by bending the wings up toward the side of
the cleaner and lift them off the pod’s hooks (fig 14).

Hayward Navigator Pro Specifications

General

Pool Type	In-ground
Warranty	2 years
Hose Diameter	1.5 inches
Pool Surface Compatibility	Concrete, Vinyl, Fiberglass
Hose Length	40 feet
Power Source	Pool's filtration system
Type	Suction-side pool cleaner
