Incorrect installation:
It’s important to keep the exhaust pipe smooth, and with no bends. Incorrect mounting can contribute to
the efficiency of the air conditioner. Ensure that the air can flow freely through the pipe.
Warning: The exhaust pipe is designed especially for this model. Do not replace or lengthen it; otherwise it
will result in failure.
Note: Maximum length of the exhaust pipe is 1500mm. It’s better to keep it the shortest length possible and
keep it horizontal.
Operation
Cooling mode
• When the A/C enters cooling mode after it’s turned on, the cooling indicator will light up.
• Press the Up/Down button to adjust the temperature (17°-30°).
• Press the Speed button to choose High/Low fan speed.
Fan mode
• When pressing the mode button or choosing the fan mode by pressing the remote control, the wind
indicator will light up.
• Press the Speed button to choose High/Low fan speed.
• Temperature cannot be set when fan mode is selected.
Dehumidifying mode
• When pressing the mode button or choosing the dehumidifying mode by
pressing the remote control, the dehumidifying indicator will light up.
• Remove the dehumidification water drainage nozzle, insert the water pipe,
and place the other end of the water pipe into the water vessel (bucket – not
supplied) or into a drainage passage, as shown in the right figure.
• After entering the dehumidifying mode, if the room temperature is more
than 15°, the compressor will work. When room temperature is less than 13°,
the compressor switches OFF; when the temperature increases to more than
15°, the compressor will restart (in order to protect the compressor, it will
restart 3 minutes later).
• In dehumidifying mode, the fan is defaulted to run at low speed, and the fan
speed cannot be adjusted.
• Temperature cannot be set.
