Hikmicro GRYPHON Series User Manual

Thermal Monocular User Manual
18
Chapter 4 Measure Distance
The device can detect the distance between the target and the observation position with laser.
Before You Start
When measuring the distance, keep the hand and the position steady. Otherwise, the accuracy
may be affected.
4.1 Measure Distance with Laser
Steps
1. Hold to show the menu.
2. Rotate the wheel to select , and press to enter the laser ranging setting interface.
3. Press to enable Laser Ranging.
4. Rotate the wheel to select the laser ranging mode and press to confirm. Once and
continuous modes are selectable.
– means measuring the distance continuously, and the measurement duration can be
selected. The measurement result will be refreshed every 1 s.
– means measuring the distance once.
5. Hold to return to the live view interface.
6. Aim the cursor at the target and press the key to measure the target distance.
Figure 4-1 Laser Ranging Result
Note
● The laser ranging function is only supported by models with laser range finder.
● When PIP is enabled, PIP view remains in the distance measurement interface.
