Hikmicro HM-TP2 Series User Manual

Handheld Thermography Camera User Manual
7
2.2 Power On/Off
Power On
Remove the lens cover, and hold for over three seconds to turn on the device. You can
observe the target when the interface of the device is stable.
Note
It may take at least 30 s until the device is ready for using when you power on it.
Power Off
When the device is turned on, hold for three seconds to power off the device.
2.2.1 Set Auto Power-off Duration
Go to Local Settings → Device Settings → Auto Off to set the automatic shutdown time for device
as required.
2.3 Operation Method
The device supports both touch-screen control and button control.
Touch-screen control
Tap on the screen to set parameters and configurations.
Figure 2-4 Touch-screen Control
Button control
Press the navigation buttons to set parameters and configurations.
