Hikmicro M10 User Manual

Handheld Thermography Camera User Manual
13
Chapter 4 Temperature Measurement
The thermography (temperature measurement) function provides the real-time temperature of
the scene and display it on the left of your screen. The thermography function is turned on by
default.
4.1 Set Thermography Parameters
You can set thermography parameters to improve the accuracy of temperature measurement.
Steps
1. Go to Local Settings → Thermography Settings.
2. Set the Thermography Range, and Emissivity, etc.
Thermography Range
Select the temperature measurement range. The device can detect the temperature and
switch thermography range automatically in Auto Switch mode.
Emissivity
Refer to Common Material Emissivity Reference to set the emissivity of your target.
Reflection Temperature
If any object (not the target) of high temperature is in the scene, and the target emissivity is
low, set the reflection temperature as the high temperature to correct the thermography
effect.
Distance
The distance between the target and the device. You can customize the target distance or
select the target distance as Near, Middle, or Far.
Environment Temperature
The average temperature of the environment.
Humidity
Set the relative humidity of current environment.
Note
Go to Local Settings → Image Settings → Display Settings to enable/disable the emissivity
display.
3. Return to previous menu to save the settings.

Hikmicro M10 Specifications

General

USB port	Yes
USB connector type	USB Type-C
Micro HDMI ports quantity	1
Sensor type	-
Fixed focal length	25 mm
Sensor resolution (thermal module)	640 x 480 pixels
Input voltage	100 - 240 V
Charging source	USB
Cables included	HDMI, USB
Number of batteries included	2 pc(s)
Battery capacity	- mAh
Battery life (max)	4 h
Battery recharge time	2.5 h
Safety	IEC 61010-1
Display type	LCD
Certification	Australian RCM
Product color	Black
Tripod thread	1/4-20 \
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
International Protection (IP) code	IP54
Accuracy	2 °C
Laser type	Class II
Laser wave power	1 mW
Laser wavelength	635 nm
Total megapixels	8 MP
Camera pixel size	17 µm
Measurement modes	Center spot, Cold spot, Hot spot, Off
Standard palettes	Black Hot, Fusion, Rain, Rainbow, Red Hot, White Hot
Maximum resolution	3264 x 2448 pixels
Infrared spectral band	8 - 14 µm
Vertical field of view	18.7 °
Horizontal field of view	24.8 °
IFOV (spatial resolution)	0.68 mRad
Thermal sensitivity (NETD)	30 mK
Sensor type (thermal module)	Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range	-20 - 650 °C
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Languages support	Multi
Management software	HIKMICRO Analyzer, HIKMICRO Viewer App, UVC Alarm Clien
Number of languages	21
Video memory capacity	64 h
Compatible memory cards	SD
Image formats supported	JPEG
Video formats supported	MP4
Maximum memory card size	128 GB
Memory capacity (images)	60000
Sustainability certificates	RoHS

Weight and Dimensions

Depth	118.3 mm
Width	284.7 mm
Height	127.1 mm
Weight	653 g
