Handheld Thermography Camera User Manual

Chapter 5 Picture and Video

Insert memory card into the device, then you can record videos, capture snapshots, and mark and

save important data.

Note

● Device does not support capturing or recording when the menu is shown.

● When the device is connected to your PC, it does not support capturing or recording.

● Go to Local Settings → Device Settings → Filename Header, you can set the filename header

for capturing or recording to distinguish the files recorded in a specify scene.

Go to Local Settings → Device Settings → Device Initialization to initialize the memory card if

needed.

5.1 Capture Picture

Steps

1. Go to Local Settings → Capture Settings.

2. Select Capture Mode to set the capture mode.

Single Capture

Capture one picture for one time.

Continuous Capture

Capture multiple pictures for one time. You can set the amount of

pictures.

Timed Capture

Device captures one picture after the specified time interval. You can

set the time interval as needed.

3. Select Picture Type to set the picture type.

Offline Picture

Select this type when analyzing the picture with the client software.

You can add remarks on the picture.

Thermal Graphic

Select this type for custom software development. Remark on the

picture is not allowed.

4. Optional: You can enable flashlight to get clear pictures in dark environment.

5. Optional: Set the optical resolution as needed.

6. Press to exit.

7. In the live view interface, pull the trigger to capture snapshot.

Questions and Answers:

Need help?

Do you have a question about the Hikmicro M10 and is the answer not in the manual?

Hikmicro M10 Specifications

General

USB port	Yes
USB connector type	USB Type-C
Micro HDMI ports quantity	1
Sensor type	-
Fixed focal length	25 mm
Sensor resolution (thermal module)	640 x 480 pixels
Input voltage	100 - 240 V
Charging source	USB
Cables included	HDMI, USB
Number of batteries included	2 pc(s)
Battery capacity	- mAh
Battery life (max)	4 h
Battery recharge time	2.5 h
Safety	IEC 61010-1
Display type	LCD
Certification	Australian RCM
Product color	Black
Tripod thread	1/4-20 \
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
International Protection (IP) code	IP54
Accuracy	2 °C
Laser type	Class II
Laser wave power	1 mW
Laser wavelength	635 nm
Total megapixels	8 MP
Camera pixel size	17 µm
Measurement modes	Center spot, Cold spot, Hot spot, Off
Standard palettes	Black Hot, Fusion, Rain, Rainbow, Red Hot, White Hot
Maximum resolution	3264 x 2448 pixels
Infrared spectral band	8 - 14 µm
Vertical field of view	18.7 °
Horizontal field of view	24.8 °
IFOV (spatial resolution)	0.68 mRad
Thermal sensitivity (NETD)	30 mK
Sensor type (thermal module)	Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range	-20 - 650 °C
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Languages support	Multi
Management software	HIKMICRO Analyzer, HIKMICRO Viewer App, UVC Alarm Clien
Number of languages	21
Video memory capacity	64 h
Compatible memory cards	SD
Image formats supported	JPEG
Video formats supported	MP4
Maximum memory card size	128 GB
Memory capacity (images)	60000
Sustainability certificates	RoHS
