Handheld Thermography Camera User Manual

Icon

Alarm Mode

Description

Interval Alarm

Set the alarm temperature section (e.g., 90 °C to

150 °C), and targets with the temperature in the

range are displayed in yellow.

Insulation Alarm

Set the alarm temperature section (e.g., 90 °C to

120 °C), targets with the temperature out of the

section (e.g., 70 °C or 125 °C) are displayed in purple

or blue.

3. Optional: Press and to select between upper limit and lower limit.

4. Press and to adjust the rule temperature.

5. Press to exit.

4.4.2 Set Alarm for Thermography Rules or Pixel-to-Pixel Thermometry

Alarm actions, such as, audible warning, sending notification to the client software, are triggered

when the tested temperature exceeds the set alarm or alert value.

Steps

1. Go to Settings → Thermography Settings → Alarm Settings.

2. Enable the function and set the alarm threshold, alert threshold, and audible warning.

Alarm Threshold

When the tested temperature exceeds the threshold, the device sends alarm notification to

the client software. It beeps if the audible warning is enabled. The frame flashes red if the

frame rule is configured.

Alert Threshold

When the tested temperature exceeds the threshold, the device sends alert notification to

the client software.

Audible Warning

The device beeps when target temperature exceeds the alarm threshold.

Note

If the frame rules are set to measure temperature, the alarm threshold, alert threshold and

audible warning settings only works in the framed areas. Otherwise, the parameters are valid

for pixel-to-pixel thermometry (whole-screen thermometry).

Questions and Answers:

Need help?

Do you have a question about the Hikmicro M10 and is the answer not in the manual?

Hikmicro M10 Specifications

General

USB port	Yes
USB connector type	USB Type-C
Micro HDMI ports quantity	1
Sensor type	-
Fixed focal length	25 mm
Sensor resolution (thermal module)	640 x 480 pixels
Input voltage	100 - 240 V
Charging source	USB
Cables included	HDMI, USB
Number of batteries included	2 pc(s)
Battery capacity	- mAh
Battery life (max)	4 h
Battery recharge time	2.5 h
Safety	IEC 61010-1
Display type	LCD
Certification	Australian RCM
Product color	Black
Tripod thread	1/4-20 \
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
International Protection (IP) code	IP54
Accuracy	2 °C
Laser type	Class II
Laser wave power	1 mW
Laser wavelength	635 nm
Total megapixels	8 MP
Camera pixel size	17 µm
Measurement modes	Center spot, Cold spot, Hot spot, Off
Standard palettes	Black Hot, Fusion, Rain, Rainbow, Red Hot, White Hot
Maximum resolution	3264 x 2448 pixels
Infrared spectral band	8 - 14 µm
Vertical field of view	18.7 °
Horizontal field of view	24.8 °
IFOV (spatial resolution)	0.68 mRad
Thermal sensitivity (NETD)	30 mK
Sensor type (thermal module)	Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range	-20 - 650 °C
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Languages support	Multi
Management software	HIKMICRO Analyzer, HIKMICRO Viewer App, UVC Alarm Clien
Number of languages	21
Video memory capacity	64 h
Compatible memory cards	SD
Image formats supported	JPEG
Video formats supported	MP4
Maximum memory card size	128 GB
Memory capacity (images)	60000
Sustainability certificates	RoHS
