Network Camera User Manual
144
if in a live view or playback.
Display Target info. on Alarm Picture: There will be a frame on the target on
the uploaded alarm picture if the checkbox is checked.
Snapshot Setting: Select the picture quality for the captured picture. Good, better, and
best are selectable.
Background Upload: Check the checkbox of background upload if you want to upload
the background picture as well.
Shield Region
The shield region allows you to set the specific region in which the face capture will
not function. Up to 4 shield regions are supported.
Steps:
1. Click the hexagons sign to draw shield area by left click end-points in the
live view window, and right click to finish the area drawing.
Notes:
● Polygon area (4~10 sides) sides is supported.
● Click to delete the drawn areas.
● If the live view is stopped, there is no way to draw the shield regions.
Draw Shield Area
2. Click Save to save the settings.
Rule
Steps:
