HIKVISION ds-2cd8153f-e User Manual

User Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
40
Figure 5-23 Adjust OSD Location
6. Click to activate above settings.
5.5.3 Configuring Text Overlay Settings
Purpose:
You can customize the text overlay.
Steps:
1. Enter the Text Overlay Settings interface:
Configuration > Advanced Configuration > Image > Text Overlay
2. Check the checkbox in front of textbox to enable the on-screen display.
3. Input the characters in the textbox.
4. Use the mouse to click and drag the red text frame in the live view
window to adjust the text overlay position.
5. Click .
Note: There are up to 4 text overlays configurable.

HIKVISION ds-2cd8153f-e Specifications

General

Brand	HIKVISION
Model	ds-2cd8153f-e
Category	Security Camera
Language	English
