HIKVISION DS-3E0105P-E User Manual

Unmanaged PoE Switch/User Manual
11
Appendix Technical
Specifications
Port
Number of port
5 * 10/100Mbps RJ45 port
High-priority port
Port 1-2
Lightning-protection
ranking
6 kV for common mode
Working mode
EXTEND OFF and EXTEND ON
Performance
Store-and-forward
Supported
MAC address table
1 K
Switching capacity
1 Gbps
PoE
PoE standard
IEEE 802.3af
Power cable
8-core
PoE port
Port 1-4
Maximum port output
15.4 W
Maximum total
output
35 W
Power
supply
Power input and
output
Input: 100~240 V AC, 50/60 Hz
Output: 48 V DC, 0.8 A
Maximum total
output
38 W
Lightning-protection
3 kV for common mode; 2 kV for differential

HIKVISION DS-3E0105P-E Specifications

General

Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	5
Maximum data transfer rate	100 Mbit/s
Input voltage	51 V
Output current	1.25 A
Power supply included	Yes
Power consumption (max)	63 W
Surge protection voltage	4 kV
Power consumption (typical)	632 W
Number of power supply units	1
10G support	No
Switch type	Unmanaged
Stackable	-
Product color	Blue
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Total Power over Ethernet (PoE) budget	58 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	15.4 W
MAC address table	1000 entries
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	93.3 mm
Width	132 mm
Height	27.6 mm
Weight	299 g
