Digital Video Recorder User Manual
203
After having finished the import of configuration files, the device will reboot automatically.
15.5 Upgrading System
Purpose
The firmware on your DVR can be upgraded by local backup device or remote FTP server.
15.5.1 Upgrading by Local Backup Device
Step 1 Connect your DVR with a local backup device where the update firmware file is located.
Step 2 Go to Menu > Maintenance > Upgrade > Local Upgrade.
Figure 15-7 Local Upgrade Interface
Step 3 Select the update file from the backup device.
Step 4 Click Upgrade to start upgrading.
Step 5 After the upgrading is completed, reboot the DVR to activate the new firmware.
15.5.2 Upgrading by FTP
Before you start
Configure PC (running FTP server) and DVR to the same Local Area Network. Run the 3
rd
-party
TFTP software on the PC and copy the firmware into the root directory of TFTP.
Step 1 Go to Menu > Maintenance > Upgrade > FTP.
Figure 15-8 FTP Upgrade Interface
Step 2 Enter the FTP Server Address in the text field.
Step 3 Click the Upgrade button to start upgrading.
Step 4 After the upgrading is completed, reboot the DVR to activate the new firmware.
15.6 Upgrading Camera
Purpose

HIKVISION DS-7104HQHI-K1 Specifications

General

Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+, H.265, H.265+
BNC input ports	1
Video input channels	4 channels
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	8 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	200 x 200 x 45 mm
