Chapter 3 Live View
3.1 Introduction of Live View
Live view shows you the video image getting from each camera in real time. The DVR will
automatically enter Live View mode when powered on. It is also at the very top of the menu
hierarchy, thus hitting the ESC many times (depending on which menu you’re on) will bring you to
the Live View mode.
Live View Icons
In the live view mode, there are icons at the right top of the screen for each channel, showing the
status of the record and alarm in the channel, so that you can know whether the channel is
recorded, or whether there are alarms occur as soon as possible.
Table 3-1 Description of Live View Icons
Icons
Description
Alarm (video loss, tampering, motion detection, VCA or sensor
alarm)
Record (manual record, schedule record, motion detection or
alarm triggered record)
Alarm & Record
Event/Exception (motion detection, sensor alarm or exception
information. For details, see Chapter 8.6 Handling Exceptions.)
3.2 Operations in Live View Mode
In live view mode, there are many functions provided. The functions are listed below.
 Single Screen: show only one screen on the monitor.
 Multi-screen: show multiple screens on the monitor simultaneously.

HIKVISION DS-7216HGHI-F1 Specifications

General

Audio input	1
BNC input ports	16
Video input channels	16 channels
USB 2.0 ports quantity	2
DC voltage	12 V
Power consumption (typical)	20 W
Bit rate	64 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	SATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1200 g
