Specifications
Table 1 Specifications of DS-9600NI-ST
Model
DS-9608NI-ST
DS-9616NI-ST
DS-9632NI-ST
Video/Audio
input
IP video
input
8-ch
16-ch
32-ch
Two-way audio
1-ch, BNC (2.0 Vp-p, 1kΩ)
Video/Audio
output
Recording
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
HDMI output
1-ch, resolution:
1920 × 1080P /60Hz, 1920×1080P /50Hz, 1600 × 1200/60Hz,
1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,
1280 × 720 /60Hz, 1024 × 768 /60Hz
Audio output
2-ch, BNC (Linear, 600Ω)
Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
8 SATA interfaces
eSATA
1 eSATA interface
Capacity
Each interface supports up to 4TB capacity for recording
External
interface
Network
interface
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial interface
1 RS-232 interface (for parameters configuration, maintenance ,
transparent channel);
1 RS-485 interface (reserved);
1 RS-485 keyboard interface (for special keyboard control)
USB interface
2, USB 2.0
Alarm in
16
Alarm out
4
Others
Power supply
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz
Consumption
(without hard
disk or
DVD-R/W)
≤ 35 W
≤ 40 W
≤ 45 W
Working
temperature
-10 ℃ ~ +55 ℃
Working
humidity
10 % ~ 90 %
Chassis
19-ich rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 ×90 mm (17.52" ×18.5"× 3.54")
Weight
≤ 8 Kg (17.64 lb) ( without hard disk or DVD-R/W )
