HIKVISION DS-9600NI-I16 Series User Manual

Network Video Recorder User Manual
103
5.4 Configuring Alarm Triggered Recording and Capture
Purpose:
Follow the procedure to configure alarm triggered recording or capture.
Step 1 Enter the Alarm settings interface.
Menu> Configuration> Alarm
Figure 5-14 Alarm Settings
Step 2 Click Alarm Input.
Figure 5-15 Alarm Settings- Alarm Input
1) Select Alarm Input number and configure alarm parameters.
2) Choose N.O (normally open) or N.C (normally closed) for alarm type.
3) Check the checkbox for Setting .
4) Click Settings.

HIKVISION DS-9600NI-I16 Series Specifications

General

Brand	HIKVISION
Model	DS-9600NI-I16 Series
Category	Network Hardware
Language	English
