HIKVISION DS-9600NI-I16 Series User Manual

Network Video Recorder User Manual
243
14.9 Configuring HDD Error Alarms
Purpose:
You can configure the HDD error alarms when the HDD status is Uninitialized or Abnormal.
Step 1 Enter the Exception interface.
Menu > Configuration > Exceptions
Step 2 Select the Exception Type to HDD Error from the dropdown list.
Step 3 Click the checkbox(s) below to select the HDD error alarm type (s), as shown in Figure 14-29.
The alarm type can be selected to: Audible Warning, Notify Surveillance Center, Send Email and
Trigger Alarm Output. Please refer to Chapter Setting Alarm Response Actions.
Figure 14-29 Configure HDD Error Alarm
Step 4 When the Trigger Alarm Output is selected, you can also select the alarm output to be
triggered from the list below.
Step 5 Click the Apply button to save the settings

HIKVISION DS-9600NI-I16 Series Specifications

General

Brand	HIKVISION
Model	DS-9600NI-I16 Series
Category	Network Hardware
Language	English
