HIKVISION DS-K1101M User Manual

14
1. Fix the plate on the wall or other
place.
1
2. Connect the cables between
controller and card reader. For
details, refer to 3.4 Wiring
Cables.
2
3
4
3. Push the card reader to match
the fixed plate.
4. Fasten the screw to keep the
components together.
Chapter 4 Sound Prompt and Indicator
After the card reader is powered on, LED status indicator will turn
blue and blink for 1 time. Then it will turn red and blink for 3
times. At last the buzzer will send out a beep sound indicating the
starting up process is completed.
During using the card reader, it will send out different sounds
prompt and the LED indicator on it have different statuses. You
can refer to tables below for detailed information.

HIKVISION DS-K1101M Specifications

General

Type	Basic access control reader
Certification	FCC, CE
Product color	Black, Silver
LED indicators	Status
Access code reader	-
Fingerprint reader	No
Authentication type	Access chip/card
Supported protocols	Mifare
RFID reading distance	50 mm
Access chip/card reader	Yes
International Protection (IP) code	IP64
Processor frequency	13.56 MHz
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
RS-485 ports	1

Weight and Dimensions

Depth	20.5 mm
Width	92.3 mm
Height	132 mm
Weight	140 g
