HIKVISION DS-K2804 Quick Start Guide

DS-K2800 Serial Access Controller
4
Chapter 2 Appearance
Component Description
Access Controller Component Schematic Diagram
Take DS-K2804 as an example, the component schematic diagram is shown below.
Figure 2-1 DS-K2804 Component Schematic Diagram
DS-K2800 Component Description Table 2-1
No.
Component Description
DS-K2801
DS-K2802
DS-K2804
1
Door Lock 1
Indicator
Door Lock 1/2
Indicator
Door Lock 1/2/3/4
Indicator
2
Power Indicator
3
Network Indicator

HIKVISION DS-K2804 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
