HIKVISION DS-K2804 User Manual

Access Control Terminal·User Manual
95
 The door status of open, close, remain open, and remain close cannot be triggered at
the same time.
 The target door and the source door cannot be the same one.
3. Click Save button to save and take effect of the parameters.
Card Linkage
Steps:
1. Click to select the linkage type as Card Linkage.
2. Input the card No. or select the card from the dropdown list.
3. Select the card reader from the table for triggering.
4. Set the linkage target, and switch the property from to to enable this function.
 Host Buzzer: The audible warning of controller will be enabled/disabled.
 Capture: The real-time capture will be enabled.
 Card Reader Buzzer: The audible warning of card reader will be enabled/disabled.
 Alarm Output: The alarm output will be enabled/disabled for notification.
 Zone: Arm or disarm the zone.
 Access Control Point: The door status of open, close, remain open, and remain closed will
be enabled.
5. Click Save button to save and take effect of the parameters.
7.10.4 Cross-Device Linkage
Purpose:
You can assign to trigger other access control device’s action by setting up a rule when the access
control event is triggered.
Click Cross-Device Linkage tab to enter the following interface.

HIKVISION DS-K2804 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
