Access Control Terminal·User Manual
90
4) (Optional) Click or to change the rule order.
5) (Optional) Select the rules in the Selected Rule list and click to remove the rule from
the list on the right.
6) Click OK to save the settings.
7) In the Custom Wiegand tab, set the rule start bit, length, and the decimal digit.
8. Click Save at the upper right corner of the interface to save the settings.
Notes:
 By default, the device disables the custom wiegand function.
 If the device enables the custom wiegand function, all wiegand interfaces in the device will
use the customized wiegand protocol.
 Up to 5 custom wiegands can be set.
 Up to 32 characters are allowed in the custom wiegand name.
 Up to 80 bits are available in the total length.
 The odd parity start bit, the odd parity length, the even parity start bit and the even parity
length range from 1 to 80 bit.
 The start bit of the card ID, the manufacturer code, the site code, and the OEM should
range from 1 to 80 bit.
 For details about the custom wiegand, see Appendix.
7.9 Searching Access Control Event
Purpose:
You can search the access control history events including device exception event, door event,
alarm input, and card reader event.
Click icon and click Access Control Event tab to enter the following interface.

HIKVISION DS-K2804 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
