HIKVISION DS-KH6320-TE1 Configuration Guide

3.3.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door staon,
doorphone, main staon, center, etc.), to which the indoor staon is linked. Linked devices for the
indoor staon refers to door staon, center, main staon, and doorphone.
With the private SIP protocol, intercom can be realized only when all these devices are in the same
network segment with the indoor
staon.
With the standard SIP protocol, intercom can be realized when all these devices support the
standard SIP protocol.
Steps
Note
●
The doorphone does not support adding with the standard SIP protocol.
●
Here take main door staon network sengs as example.
1.
Tap Sengs → → Conguraon → to enter the device management page.
Note
Default admin password is the acvaon password.
2.
Tap Main Door Staon to pop up the device informaon dialog.
Figure 3-19 Device Informaon
Set the parameters of the linked door
staon. Tap to set parameters of the door staon.
Network Indoor Staon Conguraon Guide
17

HIKVISION DS-KH6320-TE1 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Product color	Black, Grey
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	G.711u
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
