HIKVISION DS-KH6320-TE1 Configuration Guide

3.
When you slide to disable Scene Password, there is no needs to enter password during scene
mode switching.
3.4.4 Modify Unlock/Duress Code
You can create and edit the duress code and unlock password of the indoor staon.
Steps
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap Password.
Figure 3-28 Unlock and Duress Code Sengs Page
3.
Tap Unlock Password or Duress Code to pop up the password sengs dialog box.
Unlock Password
Create the indoor
staon's unlock password. If the device has connected to a lock, enter the
password to unlock.
Duress Code
When you are hijacked and forced to open the door, you can enter the duress code. An alarm
will be triggered to
nofy the management center secretly.
Note
The duress code and the unlock password cannot be the same.
4.
Create a new password and conrm it.
5.
Tap OK to save the sengs.
Network Indoor Staon Conguraon Guide
28

HIKVISION DS-KH6320-TE1 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Product color	Black, Grey
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	G.711u
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
