HIKVISION DS-KH6320-TE1 Configuration Guide

Tap Sengs → to enter the Wi-Fi Sengs page. Enable Wi-Fi. Select a Wi-Fi from the list and
enter the password of the Wi-Fi, and the indoor staon can connect to the Wi-Fi.
Figure 3-20 Wi-Fi Sengs
3.3.4 Set Indoor
Staon No.
Indoor staon No. and the indoor extension No. are numbers, which can be dialed by other devices
to call the indoor staon and the indoor extension in an intercom system. The indoor staon No., is
composed of the
oor No., room No., community No., building No. and unit No.
The indoor extension No. Should be a numeric from 1 to 5.
Up to 5 indoor extensions can be set for 1 indoor
staon.
Steps
1.
Tap
Sengs → → Conguraon → to enter the indoor staon No. sengs page.
Note
Default admin password is the acvaon password.
Network Indoor Staon Conguraon Guide
19

HIKVISION DS-KH6320-TE1 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Product color	Black, Grey
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	G.711u
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
