HIKVISION DS-KH6320-TE1 User Manual

2 Local Operaon
2.1 Call Sengs
2.1.1 Add Contact
Steps
1.
Tap Call → to enter the contact list page.
Figure 2-1 Contact List
2.
Tap to pop up the contact adding dialog.
3. Enter the contact name and the room No.
4. Tap OK to save the
sengs.
Note
Up to 200 contacts can be added.
2.1.2 Call Resident
Network Indoor Staon Operaon Guide
2

HIKVISION DS-KH6320-TE1 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Product color	Black, Grey
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	G.711u
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
