HIKVISION DS-KH6320-TE1 User Manual

Figure 2-8 Call Elevator
2.
Tap on the home page of the indoor staon to start calling the elevator.
3. When the device communicates with door
staon, tap unlock icon to start calling
the elevator.
2.7 Relay
Sengs
Aer you set the output parameters and display the relay buon on the main page,
you can control the relay manually.
Steps
1.
Tap
Sengs → → Output Sengs and disable Hide on Main Page funcon.
2.
Back to the main page and tap
.
3. Select a relay to enable or disable, the control device will start/stop working.
2.8
Informaon Management
You can view public noce, visitor message, alarm log and capture log on
informaon management page.
Tap Message on the home page to enter the
informaon management page. (Here
takes the alarm log page as an example.)
Network Indoor
Staon Operaon Guide
10

HIKVISION DS-KH6320-TE1 Specifications

General

Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Product color	Black, Grey
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	G.711u
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
