HIKVISION HWD-5108H User Manual

Digital Video Recorder User Manual
181
12.10 Configuring HDD Error Alarms
Purpose
You can configure the HDD error alarms when the HDD status is Uninitialized or Abnormal.
Step 1 Go to Menu > Configuration > Exceptions.
Step 2 Select the Exception Type to HDD Error from the drop-down list.
Step 3 Check the checkbox(s) below to select the linkage action(s) for HDD error, as shown in
Figure 12-26.
The linkage actions can be selected to: Audible Warning, Notify Surveillance Center, Send
Email and Trigger Alarm Output.
Figure 12-30 Configure HDD Error Alarm
Step 4 When the Trigger Alarm Output is selected, you can also select the alarm output to be
triggered from the list below.
Step 5 Click the Apply button to save the settings.

HIKVISION HWD-5108H Specifications

General

Brand	HIKVISION
Model	HWD-5108H
Category	Security Camera
Language	English
